5 Micron 10 Inch 20 Inch Durable SS Metal Fiber Pleated And Power Sintered Cartridge Filter
Sintered Cartridge Filter Introductions
Main filter media of pleated filter element is stainless steel sintered fiber web and stainless steel weaving wire cloth.
Stainless steel sintered fiber web is a kind of stainless steel media, sintered into a graded pore structure, the filter element enjoys the advantage of high porosity rate, big filtration area and good dirt holding capacity, and can also be used repeatedly after chemical cleaning, etc.
Stainless steel weaving wire cloth is weaved with stainless steel wire, the filter element has such characteristics of good strength, fastness, easy cleaning, high temperature resistance, low cost, etc.
Filter rating ranging from 3 micron to 200 micron is available. The size is available at customers’ requirement.
Application: mainly used in filtration of high molecular polymer, drug, hydraulic oil, water treatment, hot gas.
Sintered Cartridge Filter Specifications
Stainless steel mesh pleated and weld .resistant strong acid and alkali.it can be used for corrosive liquids liquid or gas
Highly - quality stainless steel powder sintered under high temperature .it can be used for liquid or gas under high temperature and high pressure.
| Feature | Resistant high temperature and pressure |
| Resistant strong acid and alkali |
| Small resistance in filtration process |
| Cartridges can resist to strong acid, alkaline |
| Specification | Filtration accuracy: 1-100 um |
| Length: 10-40 inch |
| Porosity: 65%-85% |
| Operating parameters | PH: 1 ~14 |
| Max.temperature: 200℃ |
| Max.differential: 0.60Mpa |
| Typical water flow rate (10 '') | |
| Typical Applications | Steam filtration |
| Decarbonization of high viscosity liquid filtration |
| Removing impuriteis in Petrochemical industry impurities Filtering |
| Strong polar solvent filtration |
| Highly corrosive liquid and gas purification |
| Liquid or gas in high temperature and pressure |
